EPDM THRU WALL OUTLET 100MM

EPDM Through Wall/Paraphet Outlet

Flexible, high quality roof outlets for corners and junctions between the roof and the parapet wall.

These EPDM outlets can be mechanically fixed and waterproofed over, or they can be bonded to a liquid membrane using the sandwich technique
They are designed to be bonded to EPDM and bituminous membranes. They can be bonded in a sandwich type of installation so the flap is secured between two layers of liquid waterproofing to ensure a good bond. Although the flap or flange is not perforated, the membrane (or adhesive) will still grip onto the material to ensure a good bond. The EPDM will tolerate a temperature of 120°C.

Alternatively they can be mechanically fixed or bonded using adhesive. The exact method of fixing will depend on the waterproofing system being used.

They ensure that the area is completely waterproofed around and into the drain pipe, so that there is no risk of water creeping behind the drainage hole and causing a leak.

The actual hole is square at 100 x 100mm wide. The pipe or shank is slightly angled to encourage the flow of water away from the mouth and down the pipe. The shank is 425mm long, so it can cross through 40cm of wall before having to be connected up.

Being made form EPDM the connector is extremely tough, fully flexible and resistant to UV deterioration and chemical salts.

They can be fitted to vertical downpipes at the edge of the retaining wall, or on a horizontal plane through the upstand or wall to then connect to the external downpipe.

A is the height of the outlet drainage hole (100mm)

L is the length of the shank or outlet pipe (100mm)

F1 is the width of the border flap or flange around the underside of the outlet hole (425mm)

F2 is the height of the border flap or flange to the left and right, and above the outlet hole (150mm)

F3 is the width of the flange (160mm)

Product code: ECO1
